[Design Patterns] 19. 동시성과 분산 시스템에서의 패턴

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

import java.util.*;
import java.util.concurrent.*;
import java.util.concurrent.atomic.*;
import java.util.function.*;
import java.util.stream.*;
import java.time.Duration;
import java.time.LocalDateTime;
import java.math.BigDecimal;
import java.net.URI;
import java.net.http.HttpClient;
import java.net.http.HttpRequest;
import java.net.http.HttpResponse;

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56

// 현대적 Thread-Safe Singleton 구현들
public class ModernSingleton {

    // 1. Enum 기반 (가장 안전)
    public enum EnumSingleton {
        INSTANCE;

        private final ConfigService configService;

        EnumSingleton() {
            this.configService = new ConfigService();
        }

        public ConfigService getConfigService() {
            return configService;
        }
    }

    // 2. Double-Checked Locking (최적화된)
    public static class DCLSingleton {
        private static volatile DCLSingleton instance;
        private final Map<String, String> config;

        private DCLSingleton() {
            // 초기화 비용이 큰 작업
            this.config = loadConfiguration();
        }

        public static DCLSingleton getInstance() {
            if (instance == null) {
                synchronized (DCLSingleton.class) {
                    if (instance == null) {
                        instance = new DCLSingleton();
                    }
                }
            }
            return instance;
        }

        private Map<String, String> loadConfiguration() {
            // 실제로는 외부 설정 로드
            return Map.of("env", "production", "db.url", "jdbc:mysql://localhost");
        }
    }

    // 3. Initialization-on-demand holder (지연 로딩 + Thread-Safe)
    public static class LazyHolder {
        private static final class Holder {
            private static final LazyHolder INSTANCE = new LazyHolder();
        }

        public static LazyHolder getInstance() {
            return Holder.INSTANCE;
        }
    }
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53

// 현대적 Producer-Consumer 구현
public class ModernProducerConsumer<T> {
    private final BlockingQueue<T> queue;
    private final AtomicBoolean running = new AtomicBoolean(true);
    private final ExecutorService producerPool;
    private final ExecutorService consumerPool;

    public ModernProducerConsumer(int capacity, int producerCount, int consumerCount) {
        this.queue = new ArrayBlockingQueue<>(capacity);
        this.producerPool = Executors.newFixedThreadPool(producerCount);
        this.consumerPool = Executors.newFixedThreadPool(consumerCount);
    }

    public void startProducers(Supplier<T> producer) {
        for (int i = 0; i < ((ThreadPoolExecutor) producerPool).getCorePoolSize(); i++) {
            producerPool.submit(() -> {
                while (running.get()) {
                    try {
                        T item = producer.get();
                        queue.put(item);
                    } catch (InterruptedException e) {
                        Thread.currentThread().interrupt();
                        break;
                    }
                }
            });
        }
    }

    public void startConsumers(Consumer<T> consumer) {
        for (int i = 0; i < ((ThreadPoolExecutor) consumerPool).getCorePoolSize(); i++) {
            consumerPool.submit(() -> {
                while (running.get() || !queue.isEmpty()) {
                    try {
                        T item = queue.poll(1, TimeUnit.SECONDS);
                        if (item != null) {
                            consumer.accept(item);
                        }
                    } catch (InterruptedException e) {
                        Thread.currentThread().interrupt();
                        break;
                    }
                }
            });
        }
    }

    public void shutdown() {
        running.set(false);
        producerPool.shutdown();
        consumerPool.shutdown();
    }
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124

// Java에서의 Actor 패턴 구현
public abstract class Actor<T> {
    private final BlockingQueue<T> mailbox = new LinkedBlockingQueue<>();
    private final AtomicBoolean running = new AtomicBoolean(false);
    private final ExecutorService executor;
    private Future<?> actorTask;

    public Actor(ExecutorService executor) {
        this.executor = executor;
    }

    public void start() {
        if (running.compareAndSet(false, true)) {
            actorTask = executor.submit(this::messageLoop);
        }
    }

    public void send(T message) {
        if (running.get()) {
            mailbox.offer(message);
        }
    }

    public void stop() {
        running.set(false);
        if (actorTask != null) {
            actorTask.cancel(true);
        }
    }

    protected abstract void handle(T message);

    private void messageLoop() {
        while (running.get()) {
            try {
                T message = mailbox.poll(1, TimeUnit.SECONDS);
                if (message != null) {
                    handle(message);
                }
            } catch (InterruptedException e) {
                Thread.currentThread().interrupt();
                break;
            }
        }
    }
}

// 구체적인 Actor 구현
//
// 액터가 주고받는 주문 페이로드는 `OrderRequest`라는 별도 타입으로 정의한다. 뒤의 "Event Sourcing" 절에서
// 다룰 Aggregate `Order`(id·customerId·items·status를 갖는 상태 전체)와 이름을 공유하면, 액터 메시지의
// 페이로드(상품 ID와 수량만 담은 값 객체)와 애그리게잇(주문의 전체 생명주기를 관리하는 도메인 객체)이 같은
// 개념인 것처럼 오독될 수 있기 때문이다. 두 타입은 필드도 책임도 다르므로 이름부터 구분한다.
public enum OrderMessageType { PROCESS_ORDER, GET_STATS }

public class OrderRequest {
    private final String productId;
    private final int quantity;

    public OrderRequest(String productId, int quantity) {
        this.productId = productId;
        this.quantity = quantity;
    }

    public String getProductId() { return productId; }
    public int getQuantity() { return quantity; }
}

public class StatsMessage {
    private final Map<String, Integer> counts;

    public StatsMessage(Map<String, Integer> counts) {
        this.counts = counts;
    }

    public Map<String, Integer> getCounts() { return counts; }
}

public class OrderMessage {
    private final OrderMessageType type;
    private final OrderRequest order;
    private final Actor<StatsMessage> sender;

    public OrderMessage(OrderMessageType type, OrderRequest order, Actor<StatsMessage> sender) {
        this.type = type;
        this.order = order;
        this.sender = sender;
    }

    public OrderMessageType getType() { return type; }
    public OrderRequest getOrder() { return order; }
    public Actor<StatsMessage> getSender() { return sender; }
}

public class OrderProcessorActor extends Actor<OrderMessage> {
    private final Map<String, Integer> orderCounts = new ConcurrentHashMap<>();

    public OrderProcessorActor(ExecutorService executor) {
        super(executor);
    }

    @Override
    protected void handle(OrderMessage message) {
        switch (message.getType()) {
            case PROCESS_ORDER:
                processOrder(message.getOrder());
                break;
            case GET_STATS:
                sendStats(message.getSender());
                break;
        }
    }

    private void processOrder(OrderRequest order) {
        // 주문 처리 로직
        orderCounts.merge(order.getProductId(), 1, Integer::sum);
        System.out.println("Processed order for: " + order.getProductId());
    }

    private void sendStats(Actor<StatsMessage> sender) {
        StatsMessage stats = new StatsMessage(new HashMap<>(orderCounts));
        sender.send(stats);
    }
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94

// Circuit Breaker 패턴 구현
public class CircuitBreaker {
    public enum State { CLOSED, OPEN, HALF_OPEN }

    private final String name;
    private final int failureThreshold;
    private final Duration timeout;
    private final Duration retryTimeout;

    private State state = State.CLOSED;
    private int failureCount = 0;
    private long lastFailureTime = 0;
    private long lastRetryTime = 0;

    public CircuitBreaker(String name, int failureThreshold, Duration timeout, Duration retryTimeout) {
        this.name = name;
        this.failureThreshold = failureThreshold;
        this.timeout = timeout;
        this.retryTimeout = retryTimeout;
    }

    public <T> T execute(Callable<T> operation) throws Exception {
        if (state == State.OPEN) {
            if (System.currentTimeMillis() - lastFailureTime >= retryTimeout.toMillis()) {
                state = State.HALF_OPEN;
                lastRetryTime = System.currentTimeMillis();
            } else {
                throw new CircuitBreakerOpenException("Circuit breaker is OPEN for " + name);
            }
        }

        try {
            T result = operation.call();
            onSuccess();
            return result;
        } catch (Exception e) {
            onFailure();
            throw e;
        }
    }

    private void onSuccess() {
        failureCount = 0;
        state = State.CLOSED;
    }

    private void onFailure() {
        failureCount++;
        lastFailureTime = System.currentTimeMillis();

        if (failureCount >= failureThreshold) {
            state = State.OPEN;
        }
    }
}

// 사용 예시
public class ExternalServiceClient {
    private final CircuitBreaker circuitBreaker;
    private final HttpClient httpClient;

    public ExternalServiceClient() {
        this.circuitBreaker = new CircuitBreaker("external-service", 5,
            Duration.ofSeconds(30), Duration.ofMinutes(1));
        this.httpClient = HttpClient.newHttpClient();
    }

    public String callExternalService(String data) {
        try {
            return circuitBreaker.execute(() -> {
                HttpRequest request = HttpRequest.newBuilder()
                    .uri(URI.create("https://api.external-service.com/process"))
                    .POST(HttpRequest.BodyPublishers.ofString(data))
                    .build();

                HttpResponse<String> response = httpClient.send(request,
                    HttpResponse.BodyHandlers.ofString());

                if (response.statusCode() != 200) {
                    throw new RuntimeException("Service returned: " + response.statusCode());
                }

                return response.body();
            });
        } catch (Exception e) {
            return handleFailure(e);
        }
    }

    private String handleFailure(Exception e) {
        // 대체 로직 또는 캐시된 데이터 반환
        return "Service temporarily unavailable";
    }
}
