| // GUI 컴포넌트 시스템
abstract class UIComponent {
protected String name;
protected int x, y, width, height;
protected boolean visible = true;
public UIComponent(String name, int x, int y, int width, int height) {
this.name = name;
this.x = x;
this.y = y;
this.width = width;
this.height = height;
}
// 모든 컴포넌트가 구현해야 하는 기본 메서드들
public abstract void render(Graphics g);
public abstract void handleEvent(Event event);
public abstract Rectangle getBounds();
// Composite 전용 메서드들
public void add(UIComponent component) {
throw new UnsupportedOperationException("Cannot add children to leaf component");
}
public void remove(UIComponent component) {
throw new UnsupportedOperationException("Cannot remove children from leaf component");
}
public List<UIComponent> getChildren() {
return Collections.emptyList();
}
// 공통 기능
public void setVisible(boolean visible) {
this.visible = visible;
}
public boolean isVisible() {
return visible;
}
public String getName() {
return name;
}
}
// Leaf 컴포넌트들
class Button extends UIComponent {
private String text;
private Runnable clickHandler;
public Button(String name, int x, int y, String text) {
super(name, x, y, 100, 30);
this.text = text;
}
@Override
public void render(Graphics g) {
if (!visible) return;
g.drawRect(x, y, width, height);
g.drawString(text, x + 10, y + 20);
System.out.println("Rendering button: " + text + " at (" + x + "," + y + ")");
}
@Override
public void handleEvent(Event event) {
if (!visible) return;
if (event.getType() == EventType.CLICK &&
event.getX() >= x && event.getX() <= x + width &&
event.getY() >= y && event.getY() <= y + height) {
System.out.println("Button clicked: " + text);
if (clickHandler != null) {
clickHandler.run();
}
}
}
@Override
public Rectangle getBounds() {
return new Rectangle(x, y, width, height);
}
public void setClickHandler(Runnable handler) {
this.clickHandler = handler;
}
}
class Label extends UIComponent {
private String text;
public Label(String name, int x, int y, String text) {
super(name, x, y, text.length() * 8, 20);
this.text = text;
}
@Override
public void render(Graphics g) {
if (!visible) return;
g.drawString(text, x, y + 15);
System.out.println("Rendering label: " + text + " at (" + x + "," + y + ")");
}
@Override
public void handleEvent(Event event) {
// 라벨은 이벤트를 처리하지 않음
}
@Override
public Rectangle getBounds() {
return new Rectangle(x, y, width, height);
}
}
// Composite 컴포넌트들
class Panel extends UIComponent {
private List<UIComponent> children = new ArrayList<>();
private Color backgroundColor;
public Panel(String name, int x, int y, int width, int height) {
super(name, x, y, width, height);
}
@Override
public void add(UIComponent component) {
children.add(component);
}
@Override
public void remove(UIComponent component) {
children.remove(component);
}
@Override
public List<UIComponent> getChildren() {
return new ArrayList<>(children);
}
@Override
public void render(Graphics g) {
if (!visible) return;
// 자신의 배경 렌더링
if (backgroundColor != null) {
g.setColor(backgroundColor);
g.fillRect(x, y, width, height);
}
g.drawRect(x, y, width, height);
System.out.println("Rendering panel: " + name + " at (" + x + "," + y + ")");
// 모든 자식 컴포넌트 렌더링 (재귀적)
for (UIComponent child : children) {
child.render(g);
}
}
@Override
public void handleEvent(Event event) {
if (!visible) return;
// 이벤트를 모든 자식에게 전달 (재귀적)
for (UIComponent child : children) {
child.handleEvent(event);
}
}
@Override
public Rectangle getBounds() {
return new Rectangle(x, y, width, height);
}
public void setBackgroundColor(Color color) {
this.backgroundColor = color;
}
}
class Window extends UIComponent {
private List<UIComponent> children = new ArrayList<>();
private String title;
private boolean minimized = false;
public Window(String name, int x, int y, int width, int height, String title) {
super(name, x, y, width, height);
this.title = title;
}
@Override
public void add(UIComponent component) {
children.add(component);
}
@Override
public void remove(UIComponent component) {
children.remove(component);
}
@Override
public List<UIComponent> getChildren() {
return new ArrayList<>(children);
}
@Override
public void render(Graphics g) {
if (!visible) return;
// 윈도우 프레임 렌더링
g.drawRect(x, y, width, height);
g.fillRect(x, y, width, 25); // 타이틀 바
g.drawString(title, x + 5, y + 18);
System.out.println("Rendering window: " + title + " at (" + x + "," + y + ")");
if (minimized) return;
// 클라이언트 영역의 자식 컴포넌트들 렌더링
for (UIComponent child : children) {
child.render(g);
}
}
@Override
public void handleEvent(Event event) {
if (!visible || minimized) return;
// 타이틀 바 클릭 확인
if (event.getType() == EventType.CLICK &&
event.getX() >= x && event.getX() <= x + width &&
event.getY() >= y && event.getY() <= y + 25) {
System.out.println("Window title bar clicked: " + title);
return;
}
// 이벤트를 자식들에게 전달
for (UIComponent child : children) {
child.handleEvent(event);
}
}
@Override
public Rectangle getBounds() {
return new Rectangle(x, y, width, height);
}
public void minimize() {
this.minimized = true;
}
public void restore() {
this.minimized = false;
}
}
// 복잡한 GUI 구조 생성 예시
public class GUIExample {
public static void main(String[] args) {
// 메인 윈도우 생성
Window mainWindow = new Window("mainWindow", 100, 100, 400, 300, "My Application");
// 상단 패널 (버튼들)
Panel topPanel = new Panel("topPanel", 10, 35, 380, 50);
topPanel.add(new Button("saveBtn", 10, 10, "Save"));
topPanel.add(new Button("loadBtn", 120, 10, "Load"));
topPanel.add(new Button("exitBtn", 230, 10, "Exit"));
// 중앙 패널 (내용)
Panel centerPanel = new Panel("centerPanel", 10, 95, 380, 150);
centerPanel.add(new Label("titleLabel", 10, 10, "Document Title:"));
centerPanel.add(new Label("contentLabel", 10, 40, "Content goes here..."));
// 하단 패널 (상태)
Panel bottomPanel = new Panel("bottomPanel", 10, 255, 380, 30);
bottomPanel.add(new Label("statusLabel", 10, 5, "Ready"));
// 윈도우에 패널들 추가
mainWindow.add(topPanel);
mainWindow.add(centerPanel);
mainWindow.add(bottomPanel);
// 중첩된 윈도우 추가
Window dialogWindow = new Window("dialog", 200, 150, 200, 150, "Settings");
Panel dialogPanel = new Panel("dialogPanel", 10, 35, 180, 80);
dialogPanel.add(new Label("settingLabel", 10, 10, "Setting:"));
dialogPanel.add(new Button("okBtn", 10, 40, "OK"));
dialogPanel.add(new Button("cancelBtn", 100, 40, "Cancel"));
dialogWindow.add(dialogPanel);
// 전체 화면 렌더링
Graphics mockGraphics = new MockGraphics();
System.out.println("=== Rendering Main Window ===");
mainWindow.render(mockGraphics);
System.out.println("\n=== Rendering Dialog Window ===");
dialogWindow.render(mockGraphics);
// 이벤트 처리 테스트
System.out.println("\n=== Event Handling Test ===");
Event clickEvent = new Event(EventType.CLICK, 120, 110); // Save 버튼 클릭
mainWindow.handleEvent(clickEvent);
}
}
// 재귀적 구조 순회 유틸리티
public class CompositeUtils {
// 깊이 우선 탐색으로 모든 컴포넌트 찾기
public static List<UIComponent> findAll(UIComponent root, Predicate<UIComponent> condition) {
List<UIComponent> result = new ArrayList<>();
findAllRecursive(root, condition, result);
return result;
}
private static void findAllRecursive(UIComponent component, Predicate<UIComponent> condition, List<UIComponent> result) {
if (condition.test(component)) {
result.add(component);
}
for (UIComponent child : component.getChildren()) {
findAllRecursive(child, condition, result);
}
}
// 특정 이름으로 컴포넌트 찾기
public static Optional<UIComponent> findByName(UIComponent root, String name) {
return findAll(root, comp -> comp.getName().equals(name))
.stream()
.findFirst();
}
// 트리 구조 출력
public static void printTree(UIComponent root) {
printTreeRecursive(root, 0);
}
private static void printTreeRecursive(UIComponent component, int depth) {
String indent = " ".repeat(depth);
System.out.println(indent + component.getClass().getSimpleName() + ": " + component.getName());
for (UIComponent child : component.getChildren()) {
printTreeRecursive(child, depth + 1);
}
}
// 총 컴포넌트 개수 계산
public static int countComponents(UIComponent root) {
return 1 + root.getChildren().stream()
.mapToInt(CompositeUtils::countComponents)
.sum();
}
// 최대 깊이 계산
public static int maxDepth(UIComponent root) {
if (root.getChildren().isEmpty()) {
return 1;
}
return 1 + root.getChildren().stream()
.mapToInt(CompositeUtils::maxDepth)
.max()
.orElse(0);
}
}
|
